Modelling faults and switching events in electrical networks

Key Takeaways

• Start with a measurable study goal, then match model detail to the specific transient or duty you must verify.
• Use EMT only when waveform timing and switching physics will change the decision, and use RMS for broad screening and longer time windows.
• Protect accuracy first with disciplined event timing, fault impedance, and boundary equivalents, then improve speed through focused network reduction and time step control.

Accurate fault and switching models will give you transient results you can trust.

Fault studies only pay off when the model matches the event you’re trying to understand, not just the one you can simulate quickly. Power interruptions are costly enough that avoidable modelling errors matter, with a Lawrence Berkeley National Laboratory study estimating about $44 billion per year in outage costs for U.S. electricity customers. That kind of impact is why disciplined fault and switching event modelling is worth the effort.

“The practical stance is simple: start with the study goal, pick the lightest model that can still answer it, and only then optimize speed.”

Breaker operations, fault impedance, and protection timing sit right on the line between “good enough” and “misleading.” Getting those details right will save you from confident looking plots that point to the wrong engineering action.

Start with the fault and switching study goals

Define the goal in terms of a measurable outcome and a pass fail check. You should know if you’re validating protection operation, checking equipment duty, or confirming ride through behaviour. Each goal implies a different time window, network detail, and output set. Clear goals stop you from overbuilding models that run slowly but answer nothing.

Lock down a minimum set of study inputs before you touch model detail. This keeps the team aligned on what must be accurate and what can be simplified. It also makes reruns and reviews much easier, since you can see what changed and why. These five items are usually enough to start well:

• Define the fault types and switching events you must represent
• Set the exact event times and required sequencing constraints
• Choose the outputs that decide pass fail for your study
• Confirm the source strength assumptions at the study boundary
• Agree on acceptable run time and acceptable error bands

Goal clarity also forces a useful question early: do you need waveform detail, or do you need system level trends. If your answer is “both,” split the work into phases, since one model rarely serves both needs well. That split is also where most simulation time savings come from, without cutting corners on the part that matters.

Choose EMT or RMS simulation based on transient detail

EMT simulation is the right choice when switching transients, harmonics, and fast control interactions matter. RMS simulation is the right choice when you mainly need phasor magnitude and angle behaviour over longer periods. The selection should follow the time scale of the phenomenon you’re studying. Picking EMT for every case will slow you down and still won’t fix poor event modelling.

EMT uses small time steps to resolve high frequency content, so it captures breaker prestrike, transformer inrush, and converter switching effects when model detail supports it. RMS assumes sinusoidal steady behaviour within each step, so it suits load flow, slower voltage recovery, and stability style studies. A common workflow uses EMT for the first tens or hundreds of milliseconds, then shifts to RMS once the fast energy exchange settles. That handoff only works if you define what “settled” means in your outputs.

Tooling matters less than model transparency when you need to justify results. SPS SOFTWARE supports physics-based EMT and RMS modelling where you can inspect and edit component behaviour, which helps teams stay consistent across study types. That consistency is a practical advantage when results must survive review and reuse. It also helps you avoid hidden assumptions that only show up after you’ve spent hours on runs.

Model short circuit faults with location impedance and timing

Fault simulation in power systems starts with three choices that control most outcomes: fault type, fault impedance, and the exact time of inception and clearing. Location matters because network impedance changes with distance and topology. Timing matters because the voltage angle at inception sets the first peak. If those inputs are vague, the results will be vague too.

Most studies should prioritize single line to ground representation, since that fault class dominates many systems. Single line to ground faults are often cited as about 70% of power system faults in instructional protection material. That statistic is useful because it tells you where modelling effort will pay back first. It also supports using multiple impedance values, since “solid” and “resistive” ground faults stress different parts of the system.

Fault impedance should reflect the physical path, not just a convenient number. Arc resistance, tower footing, cable sheath return, and contact surface conditions all shift current magnitude and DC offset decay. Clearing time should be tied to the protection and breaker sequence you expect, including any intentional delay. If the study target is equipment duty, you also need to model how the network upstream is represented, since a weak Thevenin source can cut peaks sharply.

Represent breaker and switch operations with realistic contact behaviour

Breaker modelling should match the stress you’re checking, not just the logic you’re implementing. An ideal switch that toggles open and closed at a time instant will often be fine for phasor studies. EMT fault analysis needs more care, since contact parting, arc extinction, and restrike can shape the first few milliseconds. Switching event modelling becomes misleading when the breaker is treated as perfectly clean.

Start with the simplest representation that still captures the key quantities. Controlled switching needs a model that respects current zero crossing, since mechanical opening time and pole scatter affect interruption. Transformer energization studies need prestrike behaviour to get inrush right, since the effective closing angle is rarely the commanded time. Capacitor bank switching can need preinsertion elements or damping if you’re evaluating transient overvoltage.

Contact behaviour also ties directly to how you align events in the simulation. A breaker command time is not the same as contact separation time, and a trip signal is not the same as current interruption. Model event delays explicitly, keep them consistent across phases, and document them as parameters. That habit makes sensitivity checks easier when someone questions why one run looks different from another.

Handle protection logic reclosing and transient fault clearing

Protection and reclosing logic must be represented as a sequence of measurements, decisions, and actuator delays, not just a single open command. Transient faults clear only if arc extinction and deionization are plausible within the dead time. If you skip these mechanics, you can accidentally “prove” a scheme works when it depends on timing that the field will never achieve. You’ll get the most value when protection and breaker models share the same timing assumptions.

Consider an overhead 25 kV feeder with a recloser protecting a lateral. A line to ground flashover occurs at 0.12 s with 15 ohms of fault resistance, the relay asserts a trip after 25 ms of filtering, and contacts part 35 ms later with a 400 ms dead time before reclosing. The simulated voltage recovery and the second close current will look completely different if the dead time is 200 ms, or if you assume instantaneous interruption at the trip time. That single timing chain often decides if the transient fault clears cleanly or becomes a sustained event.

Accurate relay behaviour does not require modelling every internal block, but it does require matching what the relay “sees.” Filtering, phasor estimation window length, and CT saturation can all shift operate time and element security. Align those assumptions with the study goal, then check sensitivity to the timing parameters you can’t control tightly. When results hinge on a few milliseconds, the right response is usually better modelling discipline, not more optimism.

Improve simulation speed while keeping switching transients accurate

Simulation speed improves most when you reduce unnecessary bandwidth and unnecessary network detail, while keeping the event physics intact. EMT runs slow mainly because of small time steps and large state counts. You can shorten runs by focusing high fidelity only around the faulted area and the switching devices that drive the transient.

“Speed work should never start until you know which waveforms must remain trustworthy.”

Network reduction is often the safest first move. Replace distant parts of the grid with Thevenin equivalents that match short circuit strength and X to R ratio over the frequency range you care about. Keep transformers, cables, and reactors that shape transient voltage and current near the switching point. Set a time window that ends once the quantity of interest settles, since modelling an extra second at EMT resolution can waste most of your runtime.

Time step selection deserves equal care. Too large a step will smooth peaks, distort interruption, and shift protection timing. Too small a step will bury you in computation with little gain. A good practice is to run one high-fidelity baseline case, then adjust reductions and step size until key peaks and timings stay within your acceptance bands.

Validate results and avoid common fault modelling mistakes

Validation means checking that the simulation behaves like a power system, not like a plot generator. You should verify that pre-fault load flow and voltages match expectations, and that fault current levels are consistent with short circuit calculations. Energy storage elements must show physically reasonable exchange, especially during switching. If those checks fail, speed and detail choices won’t rescue the study.

Common mistakes tend to cluster around timing and boundaries. Trip time is often confused with contact separation, and close time is often confused with effective electrical closing angle. Source equivalents get reused across cases even when topology changes, which quietly shifts fault level and DC offset. Fault impedance is set to zero for convenience, then the results are used to justify protection settings that will never see that condition.

Good fault simulation power systems work is mostly disciplined repetition, not heroic modelling. You’ll get better outcomes when every case has the same event definitions, parameter naming, and validation checks, since differences then become meaningful rather than accidental. SPS SOFTWARE fits well when you need transparent models that can be inspected and controlled, since trust builds from what you can explain, not what you can run. The strongest studies finish with a simple judgment: if the result cannot be defended from inputs to waveforms, it is not ready to guide an engineering choice.
